Description
- Capacity: 850VA / ~480W – 510W
- Topology: Line-Interactive with Automatic Voltage Regulation (AVR)
- Voltage Range: 140V – 300V AC (Input); 230V ±10% (Output)
- Battery Type: 12V, 7Ah or 9Ah sealed lead-acid maintenance-free battery
- Backup Time: Approximately 10–20 minutes at moderate loads (e.g., 200W), or ~5-15 mins depending on total load
- Recharge Time: 6–8 hours to 90–100% capacity
- Transfer Time: 2–6 milliseconds (fast switching)
- Waveform: Stepped/Modified Sine Wave
- Protection: Surge, Overload, Short Circuit, and Overcharge Protection
- Indicators: LED Status Indicators (Green/Yellow/Red) and Audible Alarms
