Description
- Capacity: 650VA / 390 Watts
- Topology: Line Interactive / Offline with AVR
- Input Voltage Range: 140V – 300V AC
- Output Voltage: 230V AC (±10%)
- Battery Type: Internal 12V / 7Ah Sealed Lead-Acid (SLA)
- Recharge Time: Approximately 6–8 hours to 90% capacity
- Backup Time: 10–20 minutes (depending on load)
- Transfer Time: <10ms (typical)
- Outlets: Usually 2 x 3-pin universal/Indian standard sockets
- Waveform: Stepped approximation to a sine wave (simulated)
- Protection: Overload, short-circuit, spike/surge suppression, and boost/buck AVR
- Indicators: Three LED indicators (Power, Battery, Fault/Replace Battery)
- Warranty: 1-year on the battery.
